"Compact Size, Big Power — The 'Mighty Powerhouse' of Residential Variable-Frequency Air Conditioning"
The Panasonic SBP 120-185cc series is specifically designed for 3-5HP residential variable-frequency air conditioners and small VRF systems. Its volume is reduced by 15% compared to previous models of the same displacement, facilitating an integrated electrical control box layout and freeing up more space for the outdoor unit design.
The selection guide is clear at a glance: The H16 series (e.g., C-SBP170H16Y) focuses on high-speed operation, with a maximum allowable speed of up to 130 rps — delivering "instant response" for cooling and heating, ideal for users who demand rapid temperature changes. The H36 series emphasizes low-frequency stability, with minimal vibration below 15 rps, making it suitable for prolonged constant-temperature dehumidification scenarios. The H38 series serves as the standard 220V residential voltage platform. With a robust housing and seamless interfaces, virtually no mechanical noise is audible upon startup — Panasonic quality reveals its true excellence in every detail.
Included Models: C-SBP120H38A, C-SBP120H38B, C-SBP150H16A, C-SBP160H16A, C-SBP170H16Y, C-SBP205H16Y, C-SBP140H36A, C-SBP140H36B, C-SBP160H36A, C-SBP160H36B, C-SBP170H36A, C-SBP170H36B, C-SBP185H36A
Product Positioning: 3-5HP residential variable-frequency wall-mounted units, small VRF systems, and rapid cooling/heating systems.
Technical Features:
H16 Series (16A/16Y): Focuses on high-speed operation, with a maximum allowable speed of up to 130 rps, suitable for rapid cooling and heating demands.
H36 Series: Emphasizes low-frequency stability, with minimal vibration below 15 rps, ideal for prolonged constant-temperature dehumidification.
H38 Series: Standard 220-240V residential voltage platform.
Compact design with a 15% reduction in volume compared to previous models of the same displacement.
High-precision mating + tip seals to close the disengagement gap between the orbiting and fixed scrolls caused by axial force.
Suitable Applications: Residential variable-frequency wall-mounted units, 3-5HP small VRF systems, rapid cooling/heating requirements.
