Sanyo B6(60Hz 208-230V) Refrigeration Compressor C-SBP105H16A C-SBP120H16A C-SBP130H16A C-SBP140H16A-Quality Heat Exchange Parts

Sanyo B6(60Hz 208-230V) Refrigeration Compressor C-SBP105H16A C-SBP120H16A C-SBP130H16A C-SBP140H16A-Quality Heat Exchange Parts

Name: Sanyo B6(60Hz 208-230V) Refrigeration Compressor C-SBP105H16A C-SBP120H16A C-SBP130H16A C-SBP140H16A-Quality Heat Exchange Parts
Brand: SANYO
Rating: 5.0 (11 reviews)

C-SBP Series (3–4 HP) — Single-phase 208-230V/60Hz R410A scroll compressors by Panasonic/Sanyo. Compact, lightweight, drop-in ready for North American small commercial A/C & heat pumps. COP 2.76–2.90 | EER up to 9.89.

Model:
C-SBP105H16A C-SBP120H16A C-SBP130H16A C-SBP140H16A
Brand:
SANYO

Availability:

Quantity:



Inquire Add to Basket

Product Description

I. Positioning

The C-SBP series is Panasonic/Sanyo's product line of hermetic scroll compressors optimized for R410A refrigerant, covering five capacity grades: C-SBP105, C-SBP120, C-SBP130, C-SBP140, and C-SBP185. With its core features being single-phase 208-230V/60Hz power compatibility and a compact 3–4 HP power range, the series is the ideal power choice for small commercial air conditioning and heat pump systems in North America and other 60Hz regions.

Feature Dimension	Description
Power Range	3 HP – 4 HP
Refrigerant	R410A
Power Supply	Single-phase 208-230V/60Hz
Application Condition	High-temp A/C and heat pumps

II. Full Series Parameter Comparison Table

Condition: 60Hz, R410A refrigerant.

No.	Model	Nominal HP	Displacement (cm³)	Cooling Capacity (W)	Cooling Capacity (Btu/h)	COP	EER	Net Weight (kg)
1	C-SBP105H16A	3.0	35.0	10,500	35,849	2.76	9.42	—
2	C-SBP120H16A	3.5	39.9	12,100	41,312	2.81	9.59	—
3	C-SBP130H16A	3.7	42.4	13,200	45,067	2.87	9.79	—
4	C-SBP140H16A	4.0	46.4	14,300	48,823	2.90	9.89	—

*Note: The C-SBP185 model is listed in the series overview but not included in the detailed parameter table above.

III. Detailed Analysis

Feature: The C-SBP series adopts single-phase 208-230V/60Hz power, adapting to residential and commercial power conditions in North America and other 60Hz regions. The compressor uses a hermetic scroll structure with fewer parts, low vibration, and low noise. Its lightweight design facilitates easy installation and transportation.
Advantage: The series' core strengths are compact lightweight construction and single-phase power compatibility. The 3–4 HP power coverage precisely matches the demands of small commercial air conditioning and heat pump systems. COP reaches 2.76–2.90 and EER reaches 9.42–9.89 Btu/Wh, delivering solid energy efficiency.
Benefit: For small commercial A/C and heat pump systems in the North American market, the C-SBP series' single-phase compatibility eliminates the need for three-phase power upgrades, significantly reducing installation costs. For equipment manufacturers, the four capacity grades from C-SBP105 to C-SBP140 provide fine-grained cooling capacity matching options. For end users, the compact lightweight design reduces equipment integration and on-site installation difficulty.

IV. Application Quick Selection Guide

Application Scenario	Recommended Model	HP	Key Advantage
Small commercial A/C	C-SBP105H16A	3.0	10.5 kW, lightweight
Small commercial heat pump	C-SBP120H16A	3.5	12.1 kW, COP 2.81
Small commercial A/C / Heat pump	C-SBP130H16A	3.7	13.2 kW, COP 2.87
Small commercial A/C	C-SBP140H16A	4.0	14.3 kW, COP 2.90

LOGISTICS SOLUTIONS物流解决方案 Logistics & Transportation

Single-Phase R410A Scroll — No Three-Phase Upgrade Required.

If your small commercial project (restaurant, convenience store, small office) only has single-phase 208-230V power, the C-SBP series is your answer. 3.0–4.0 HP in four fine-grained steps (C-SBP105 → C-SBP140), lightweight hermetic scroll design, low vibration, low noise. Drop-in ready for 60Hz markets.

Let's get your project powered. Reach out for model recommendations, cross-reference support, and volume pricing.

RELATED PRODUCTS

Brand New C-SBP185H38A Scroll Compressor for Refrigeration Freezing Cooling Machines
