Brand New C-SBP185H38A Scroll Compressor for Refrigeration Freezing Cooling Machines

I. Positioning

II. Core Technical Parameters

III. Detailed Analysis

•


  Feature: The C-SBP185H38A adopts a hermetic scroll structure, with the motor and scroll set sealed within a welded housing to minimize refrigerant leakage points. The scroll plates feature an axial compliance design, allowing micro-separation during operation so that liquid refrigerant and contaminants can pass through without causing damage, thereby enhancing compressor reliability. The compressor is factory-charged with FV68S refrigerant oil (1,700 ml), with a shell net weight of 40 kg — compact and easy to install.




•


  Advantage:




•


  High-pressure dedicated platform: Engineered from the ground up for R410A, whose operating pressure is approximately 60% higher than R22. Scroll plate end-face seal clearances are precisely calculated to minimize leakage under high-pressure differentials; motor windings use high-quality insulating materials to prevent corona discharge; shell wall thickness and welding processes are reinforced to withstand higher burst pressures.




•


  Dual-frequency high efficiency: Maintains high energy efficiency under both 50Hz and 60Hz. COP reaches 2.92 at 50Hz and 3.07 at 60Hz, meaning every 1 kW of electricity consumed produces over 3 kW of cooling output.




•


  Compact & lightweight: At 40 kg net weight, it offers significant lightweight advantage among compressors of the same power grade, facilitating equipment integration and on-site installation.




•


  Benefit: For industrial A/C and chiller manufacturers, the C-SBP185H38A's cooling capacity of 15.2 kW (50Hz) / 18.7 kW (60Hz) precisely matches 5.5 HP-class commercial A/C systems, reducing system design redundancy or insufficiency. For heat pump system integrators, the -15℃ evaporating temperature lower limit enables low-temperature heat pump operation, while R410A's high-efficiency characteristics ensure stable heating output. For end users, the high EER of R410A systems (COP 2.92–3.07) and the long service life of scroll compressors significantly reduce total lifecycle operating costs while guaranteeing cooling/heating performance.




IV. Application Quick Selection Guide
