"Large Displacement · High Energy Efficiency — The Golden Power for R410A Commercial Fixed-Speed Air Conditioning"
The GMCC PA-G2 series stands as the backbone of fixed-speed compressors for R410A refrigerant. With a displacement ranging from 16.5 to 25.0 cm³/rev and a cooling capacity of 5.0-7.6 kW, this single platform provides full coverage from 2.5HP cabinet units to 5HP commercial unitary systems.
Achieving a COP of up to 3.1 W/W, it delivers 6% to 8% more energy savings compared to similar products. The G2 series platform utilizes high-precision machining processes, ensuring precise pump body mating and stable operation. The entire series features a T3 tropical design, guaranteeing zero performance degradation even in high-temperature environments. With standard interfaces and easy installation, it is a worry-free choice for commercial air conditioning projects, whether for OEM matching or after-sales replacement.
Included Models: PA165G2CS-3KTM1, PA175G2CS-3KUM, PA180G2CS-3KTM1, PA180G2CS-3KTM, PA185G2CS-3KTM1, PA190G2CS-3KTM, PA195G2CS-3KTM, PA200G2CS-3KTM, PA205G2CS-3KTM, PA210G2CS-3KUM, PA215G2CS-3KUM, PA235G2CS-3KTM1, PA240G2CS-3KTM1, PA240G2CS-3MTM, PA250G2CS-3KUM
-
Product Positioning: 2.5-5HP commercial and large residential R410A fixed-speed air conditioning.
-
Core Technologies:
-
G2 Series Platform: R410A refrigerant rotary fixed-speed compressor.
-
Displacement Range: 16.5-25.0 cm³/rev.
-
Power Supply: 208-230V/60Hz, Single-phase.
-
Cooling Capacity Range: 5.0-7.6 kW.
-
COP: 3.1 W/W.
-
Suitable Applications: Large residential cabinet units, 2.5-5HP commercial unitary systems, export air conditioners.
