I. Positioning
The C-SBS series is Panasonic/Songyang's line of fully hermetic scroll compressors optimized for the environmentally friendly R407C refrigerant, covering four capacity levels: C-SBS150, C-SBS160, C-SBS165, and C-SBS235. With a medium power range of 4.2–7 HP and energy efficiency characterized by COPs of 3.10–3.18, this series is the ideal power solution for R407C commercial air conditioning, heat pump, and industrial refrigeration systems.
| Feature Dimension | Description |
| Power Range | 4.2 HP – 7 HP |
| Refrigerant | R407C |
| Power Supply | 3-Phase 380-415V/50Hz, 440-460V/60Hz |
| Application Duty | Heat pumps & air conditioning |
II. Full Series Parameter Comparison Table
| No. | Model | Nominal HP | Displacement (cm³) | Cooling Capacity 50Hz (W) | Cooling Capacity 60Hz (W) | COP 50Hz | COP 60Hz | EER 50Hz |
| 1 | C-SBS150H38C | 4.2 | 70.52 | 12,800 | 15,500 | 3.16 | 3.18 | 10.78 |
| 2 | C-SBS160H38A | 4.5 | 76.0 | — | — | — | — | — |
| 3 | C-SBS165H38C | 4.5 | 76.0 | — | — | — | — | — |
| 4 | C-SBS235H38A | 7.0 | 110.2 | 19,500 | 23,400 | 3.10 | — | 10.58 |
| 5 | C-SBS235H38B | 7.0 | 110.2 | — | — | — | — | — |
-
C-SBS150H38C: 50Hz cooling capacity 12,800W, COP 3.16, EER 10.78 Btu/Wh; 60Hz cooling capacity 15,500W, COP 3.18.
-
C-SBS235H38A: 50Hz cooling capacity 19,500W, COP 3.10, EER 10.58 Btu/Wh.
III. Detailed Overview
Feature: The C-SBS series adopts a native design for R407C systems, factory-charged with POE ester oil for perfect compatibility with R407C refrigerant. R407C is an environmentally friendly alternative to R22 with a low ozone depletion potential (ODP). The compressor utilizes a fully hermetic scroll structure with high-performance rolling bearings for main and auxiliary shafts. An internal protector ensures reliable motor protection upon direct power cutoff, and a suction strainer at the suction port provides enhanced compressor protection.
Advantage: This series centers on R407C refrigerant compatibility and high energy efficiency. The C-SBS150H38C achieves a COP of 3.16 and EER of 10.78 Btu/Wh at 50Hz. The C-SBS235H38A delivers a cooling capacity of 19,500W at 50Hz with a COP of 3.10 and EER of 10.58 Btu/Wh. The complete 4.2–7 HP power coverage meets diverse demands from small commercial air conditioners to medium industrial refrigeration systems.
Benefit: For equipment manufacturers, the C-SBS series provides precise power matching for R407C systems with a cooling capacity range of 12.8 kW to 23.4 kW. For projects targeting markets with environmental regulations, R407C's zero-ODP meets compliance requirements while maintaining high energy efficiency. For end users, the high efficiency of R407C systems combined with the long-service-life design of scroll compressors ensures long-term operational economy and reliability.
IV. Application Scenario Quick-Selection Guide
| Application Scenario | Recommended Model | HP | Key Advantage |
| R407C Small Commercial A/C | C-SBS150H38C | 4.2 | 12.8kW, COP 3.16 |
| R407C Medium Commercial A/C | C-SBS160H38A | 4.5 | 76.0cc displacement |
| R407C Heat Pump System | C-SBS165H38C | 4.5 | Different interface configuration |
| R407C Large Commercial | C-SBS235H38A | 7.0 | 19.5kW, COP 3.10 |
Selection Tip: For 4.2 HP, choose C-SBS150H38C; for 4.5 HP, choose C-SBS160H38A / C-SBS165H38C; for 7 HP, choose C-SBS235H38A/B.
Future-Proof Your Cooling Systems with R407C
The phase-down of R22 has made R407C the go-to solution for environmentally conscious operations—but only if your compressor can unlock its full potential. The Panasonic/Songyang C-SBS Series is purpose-engineered to do exactly that.
Unlike generic replacements, the C-SBS platform is natively designed for R407C with factory-filled POE ester oil, eliminating compatibility guesswork and ensuring optimal lubrication from day one. With a versatile 4.2–7 HP range and industry-leading efficiency (COP to 3.18, EER to 10.78 Btu/Wh), it bridges the gap between small commercial units and heavy-duty industrial refrigeration.
Core Advantages at a Glance:
-
Precision Engineering: Scroll wrap geometry and POE oil pairing maximize heat transfer and minimize wear under R407C's unique thermodynamic profile.
-
Flexible Integration: Four distinct models (C-SBS150/160/165/235) accommodate diverse voltage and interface requirements, simplifying system design.
From 12.8 kW to 23.4 kW, the C-SBS series delivers the exact capacity your application demands—without compromise.
Take the Next Step:
Equip your systems with a compressor built for the future. Reach out to our technical sales team for model cross-reference, volume pricing, or application engineering support.
