Danfos Scroll Parts Air Cooler Refrigeration Compressor Danfos 50Hz R407c Single HCP094T4 HCP109T4 HCP120T4 in Stock

Danfos Scroll Parts Air Cooler Refrigeration Compressor Danfoss 50Hz R407c Single HCP094T4 HCP109T4 HCP120T4 in Stock

Name: Danfos Scroll Parts Air Cooler Refrigeration Compressor Danfoss 50Hz R407c Single HCP094T4 HCP109T4 HCP120T4 in Stock
Brand: DANFOSS
Rating: 5.0 (66 reviews)

• HCP094T4: Suitable for 5-7 HP commercial water chillers and medium-sized cold rooms.

• HCP109T4: Suitable for 6-9 HP modular air conditioning units and large-scale refrigeration equipment.

• HCP120T4: Suitable for 7-10 HP central air conditioning systems and industrial refrigeration systems.

Model:
HCP094T4 HCP109T4 HCP120T4
Brand:
DANFOSS

Availability:

Quantity:



Inquire Add to Basket

Product Description

I. Product Overview

The Danfoss HCP series is a highly efficient and reliable commercial fixed-speed scroll compressor, specifically optimized for the R407C refrigerant. Designed for 50Hz power supply markets, it is suitable for commercial refrigeration, air conditioning, and heat pump systems. Renowned for its exceptional energy efficiency, low-noise operation, and outstanding reliability, this series is an ideal choice for medium-sized commercial refrigeration applications.

II. Product Models and Core Parameters

Parameter	HCP094T4	HCP109T4	HCP120T4
Displacement (cm³/rev)	≈154.0	≈178.6	≈196.6
Cooling Capacity Range (kW)	≈15.5-23.5	≈18.5-28.5	≈20.5-31.5
Power (kW)	≈4.5-7.5	≈5.5-9.0	≈6.5-10.5
Voltage/Frequency	380-420V/3Ph/50Hz	380-420V/3Ph/50Hz	380-420V/3Ph/50Hz
Refrigerant	R407C	R407C	R407C
Applicable Horsepower (HP)	5-7HP	6-9HP	7-10HP
Application Fields	Commercial water chillers, freezing/cold storage, air conditioning systems	Medium-to-large commercial refrigeration/air conditioning systems	Large commercial refrigeration/air conditioning systems

III. Core Technical Advantages

Energy-Efficient Design

Utilizes optimized scroll profiles, achieving volumetric efficiency exceeding 92%.
All-aluminum housing enhances heat dissipation and reduces operating temperatures.
COP (Coefficient of Performance) reaches 3.4-3.8, surpassing industry standards by 15%.

Excellent Reliability

Patented dual-flexible design enhances resistance to liquid slugging.
Built-in oil separator ensures lubrication system reliability.
Motor insulation class F, temperature resistance up to 155°C, with a service life of up to 50,000 hours.

Environmental Compatibility

Optimized for R407C with a moderate GWP (1774).
Compatible with POE/PVE lubricants, offering excellent system compatibility.
Complies with EU Ecodesign and Chinese energy efficiency standards.

IV. Operational Performance Features

Low Noise and Vibration: Operating noise below 68 dB(A), vibration amplitude <20 μm.
Wide Operating Range: Evaporation temperature range of -25°C to +12°C, condensation temperature ≤55°C.
Quick Cold Start: Low-pressure differential start design, starting current less than 2.5 times the full-load current.
Intelligent Protection: Built-in multiple protections for temperature, pressure, and current.

V. Typical Application Scenarios

Commercial Refrigeration: Supermarket display cases, cold storage rooms, food processing cold chains.
Air Conditioning Systems: Commercial central air conditioning, modular water chillers.
Heat Pump Applications: Air-source heat pumps, industrial waste heat recovery.
Specialized Fields: Data center cooling, medical equipment temperature control.

VI. Installation and Maintenance Advantages

Compact Design: Standardized installation dimensions, compatible with mainstream racks.
Easy Maintenance: Detachable end cover design for convenient on-site inspection and repair.
