Hot Sale SZ DANFOSS Scroll Compressor SZ148/SZ160/SZ161/SZ175/SZ185/SZ240/SZ300/SZ380 R107C Single

Hot Sale SZ DANFOSS Scroll Compressor SZ148/SZ160/SZ161/SZ175/SZ185/SZ240/SZ300/SZ380 R107C Single

The Danfoss SZ Series scroll compressors are purpose-built for HFC refrigerants. With a versatile 7–30 HP range, this eco-friendly line seamlessly adapts from small commercial air conditioners to large-scale water chillers, providing the ultimate solution for sustainable cooling.

Model:
SZ084 SZ090 SZ100 SZ110 SZ115 SZ120 SZ125ac SZ148 SZ160 SZ161 SZ175 SZ185 SZ240 SZ300 SZ380
Brand:
DANFOSS

Availability:

Quantity:



Inquire Add to Basket

Product Description

I. Series Positioning

The SZ Series is Danfoss S-Series' eco-friendly line of scroll compressors, specifically optimized for HFC refrigerants. Factory-charged with POE ester oil (160SZ), it ensures full compatibility with multiple HFC refrigerants including R134a, R407C, R404A, and R507A. Positioned for 7–30 HP air conditioning and refrigeration applications, the SZ Series covers a complete power spectrum from small commercial AC units to large water chillers, making it the core solution for refrigerant eco-transition.

Feature Dimension	Description
Power Range	7 HP – 30 HP
Refrigerant	R134a / R407C / R404A / R507A
Lubricant	POE ester oil (160SZ)
Application Condition	A/C & Med-temp Refrigeration
Core Positioning	Multi-refrigerant compatibility, top choice for eco-transition

II. Full Series Parameter Comparison Table

50Hz operating condition, R407C refrigerant.

No.	Model	Nominal HP	Cooling Capacity (W)	Cooling Capacity (Btu/h)	Input Power (kW)	COP	Compatible Refrigerants
1	SZ084	7	19,300	66,000	6.13	3.15	R407C/R134a
2	SZ090	7.5	20,400	69,600	6.45	3.16	R407C/R134a
3	SZ100	8	21,600	73,700	6.84	3.15	R407C/R134a
4	SZ110	9	24,600	84,000	7.76	3.17	R407C/R134a
5	SZ115	9.5	N/A	N/A	N/A	N/A	R407C/R134a
6	SZ120	10	N/A	N/A	N/A	N/A	R407C/R134a
7	SZ125ac	10	N/A	N/A	N/A	N/A	R407C/R134a
8	SZ148	12	N/A	N/A	N/A	N/A	R407C/R134a/R404A/R507A
9	SZ160	13	N/A	N/A	N/A	N/A	R407C/R134a/R404A/R507A
10	SZ161	13	N/A	N/A	N/A	N/A	R407C/R134a/R404A/R507A
11	SZ175	14	N/A	N/A	N/A	N/A	R407C/R134a/R404A/R507A
12	SZ185	15	N/A	N/A	N/A	N/A	R407C/R134a/R404A/R507A
13	SZ240	20	N/A	N/A	N/A	N/A	R407C/R134a
14	SZ300	25	N/A	N/A	N/A	N/A	R407C/R134a
15	SZ380	30	N/A	N/A	N/A	N/A	R407C/R134a

III. Detailed Explanation

Feature – Technical Characteristics

The SZ Series inherits the core technological DNA of Danfoss S-Series scroll compressors: an intermediate thermal shield design for high energy efficiency and low noise levels; an internal check valve to prevent refrigerant leakage from the high-pressure side; a "contact-free and wear-free" scroll design to reduce friction; lead-free eco-friendly bearings; and oil sight glasses and oil equalizers for easy parallel unit setup. Factory-charged with POE ester oil (160SZ), which is key to adapting to HFC refrigerants, the SZ Series is compatible with various refrigerants such as R407C, R134a, R404A, and R507A.

Advantage – Technical Advantages

The multi-refrigerant compatibility of the SZ Series makes it an ideal choice for OEMs and contractors—a single compressor model can adapt to multiple refrigerant solutions, greatly simplifying inventory management and reducing refrigerant switching costs. Models SZ084–SZ110 achieve a COP of 3.15–3.17, delivering solid energy efficiency. Covering a complete power spectrum from 7 HP to 30 HP and available in both single and dual-unit parallel configurations, the SZ Series meets the needs of projects of all sizes. For markets undergoing an eco-friendly refrigerant transition, the SZ Series provides a one-stop compatible solution for transitioning from R22 to R407C/R134a.

Benefit – User Benefits

For OEMs: The SZ Series means one compressor fits multiple refrigerant solutions, reducing R&D costs and inventory complexity.
For Contractors: It means no need to change compressor brands or installation methods when transitioning from R22 to HFC systems, lowering technical risks and training costs.
For End-Users & Service Technicians: It means no worries about refrigerant compatibility during compressor replacement, drastically reducing downtime.

IV. Application Scenarios

Application Scenario	Recommended Models	HP Range	Why It Fits
Small Commercial AC	SZ084–SZ100	7–8	R407C/R134a compatible, COP 3.15+
Medium Commercial AC / Rooftop Units	SZ110–SZ125ac	9–10	Compact design, flexible installation
Large Commercial AC / Water Chillers	SZ148–SZ185	12–15	Full compatibility with R407C/R134a/R404A/R507A
Large Chillers / Industrial Cooling	SZ240–SZ380	20–30	Extra-large cooling capacity, multi-refrigerant adaptation

The SZ Series is widely used in commercial air conditioning, water chillers, rooftop units, precision air conditioning, industrial cooling, and more.

PACKING DELIVERING包装与交付

LOGISTICS SOLUTIONS物流解决方案 Logistics & Transportation

We are ready to provide you with model selection, quotation, and technical support at any time. We look forward to building a long-term partnership with you.
