一.Core Parameter Comparison of AEZ Series Compressors
Parameter
AEZ4425Z
AEZ3430Z
AEZ4430Z
AEZ3440Z
Horsepower (HP)
1/5 HP
1/4 HP
1/4 HP
1/3 HP
Refrigerant
R404A
R404A
R404A
R404A
Displacement Volume
4.50 cm³
5.70 cm³
5.70 cm³
7.55 cm³
Oil Charge Volume
250 cm³
250 cm³
250 cm³
350 cm³
Power Supply Voltage
220-240V/1/50Hz
220-240V/1/50Hz
220-240V/1/50Hz
220-240V/1/50Hz
二.Cooling Capacity Parameters (50Hz, Condensing Temperature 54.4°C)
Evaporation Temperature
AEZ4425Z
AEZ3430Z
AEZ4430Z
AEZ3440Z
-25℃
142W
192W
192W
287W
-15℃
198W
258W
258W
357W
-10℃
263W
346W
346W
462W
0℃
432W
550W
550W
743W
+7.2℃
587W
741W
741W
1004W
+15℃
787W
1010W
1010W
1342W
三.Selection Recommendations
Based on Temperature Requirements:
High-Temperature Applications (+7°C to +15°C): Such as commercial refrigerators, display cabinets, and air conditioning systems.
Medium/Low-Temperature Applications (-10°C to 0°C): Such as food cold storage and cold chain transportation.
Low-Temperature Applications (-25°C to -15°C): Such as ice cream cabinets and frozen food storage.
Based on Cooling Capacity Matching: Calculate the total required cooling capacity based on the size of the space to be cooled, insulation effectiveness, and product heat load, and select a model with matching or slightly higher cooling capacity.
Based on Power Supply Conditions: This series uses a single-phase 220-240V/50Hz power supply, making it highly suitable for standard commercial and residential electrical environments. It does not require industrial three-phase power, ensuring convenient installation.
