PH460X3CS-4MUA PH480X3CS-4MU1 Rotary Compressor for Refrigeration & Heat Exchange Quality Parts for Efficient Cooling & Energy Conservation

PH460X3CS-4MUA PH480X3CS-4MU1 Rotary Compressor for Refrigeration & Heat Exchange Quality Parts for Efficient Cooling & Energy Conservation

Name: PH460X3CS-4MUA PH480X3CS-4MU1 Rotary Compressor for Refrigeration & Heat Exchange Quality Parts for Efficient Cooling & Energy Conservation
Brand: GMCC
Rating: 5.0 (63 reviews)

PH480X3CS-4MU1 is a Meizhi compressor mainly used in refrigeration equipment such as air conditioners and refrigerators. ‌
Product Features
High reliability: Built in motor protector and pressure relief valve ensure stable operation of the equipment. ‌
Multiple voltage options: Adapt to different power environments and improve flexibility in use. ‌
Efficient and energy-saving: compact structure, high energy efficiency ratio, low operating noise. Wide range of cooling capacity options: suitable for different cooling needs.
Application scope
PH480X3CS-4MU1 compressor is widely used in various fields such as air conditioning, refrigerators, freezers, heat pump water heaters, dehumidifiers, dryers, refrigerated vehicles, and water dispensers

Model:
PH460X3CS-4MUA PH480X3CS-4MU1
Brand:
GMCC

Availability:

Quantity:



Inquire Add to Basket

Product Description

I. Product Overview

The PH460X3CS-4MUA and PH480X3CS-4MU1 are high-performance scroll compressors specifically designed for commercial and industrial refrigeration systems. Incorporating advanced DC inverter technology and environmentally friendly refrigerant solutions, these compressors combine high energy efficiency, low-noise operation, and strong environmental adaptability, making them suitable for medium-to-high cooling capacity applications and complex operating conditions.

II. Core Features & Advantages

1. Powerful Performance & Wide-Range High-Efficiency Operation

Large Displacement Base: With displacements of 46.0 cm³ and 48.0 cm³, the large-displacement design provides the system with powerful fundamental cooling/heating capacity, ensuring rapid response even under extreme weather conditions.
High Efficiency Under All Conditions: Utilizing advanced DC inverter technology and high-efficiency permanent magnet synchronous motors, they operate smoothly within a wide frequency range of 20 Hz to 120 Hz (or higher). They demonstrate outstanding energy efficiency not only at rated frequency but also exhibit excellent IPLV under the commonly used medium-low frequency part-load conditions, significantly reducing annual energy consumption.

2. Precise Temperature Control & Rapid Response

Stepless Smooth Adjustment: The compressor speed can be adjusted in real-time and steplessly according to the system load, completely avoiding the temperature fluctuations caused by the start-stop cycles of fixed-speed compressors, achieving precise temperature control within ±0.5°C and high comfort levels.
Rapid Cooling/Heating: During startup or sudden load changes, the compressor can quickly ramp up to high-frequency operation, reaching the set temperature in the shortest possible time.

3. Exceptional Reliability & Environmental Adaptability

Reinforced Structural Design: Core components such as the cylinder, roller, and crankshaft have been reinforced and precision-machined to handle the increased stress from the large displacement, ensuring long-term durability under high-pressure and high-temperature conditions.
Advanced Motor Technology: The motor, manufactured using vacuum impregnation, offers excellent insulation and heat dissipation, with strong overload capacity, enabling adaptation to complex power grid environments.
Optimized Liquid Slug Resistance: The pump structure is optimized for the characteristics of R32 refrigerant, enhancing its ability to handle transient system fluctuations.

4. Low Noise & Vibration

Through precise rotor dynamic balancing correction and optimized muffler design, even under large displacement conditions, operating noise and vibration are maintained at very low levels, helping the entire unit achieve higher quietness standards.

III. Typical Application Areas

Commercial Multi-Split Systems: The core component for outdoor units in central air conditioning systems for office buildings, shopping malls, and hotels.
Light Commercial Air Conditioning: Large rooftop units, air-cooled modular chillers.
Commercial Heat Pumps: District heating systems, large residential heating and hot water units.
