Technical Advantages
1. Wide Voltage Adaptability · Worry-Free for Global Power Grids
The X1 series features excellent wide voltage adaptability. The 50Hz version (with the -8DZD2 suffix) is adapted to 220-240V/50Hz power grids; the 60Hz version (with the -4DZDE2 suffix) is adapted to 208-230V/60Hz power grids. It has strong adaptability to voltage fluctuations, ensuring normal air conditioner startup and operation even in areas with unstable power grids.
2. T3 Tropical Condition Certification · Stable Output in High Temperatures
The entire series is T3 tropical condition certified. Even in extreme outdoor temperatures of 45-50°C, the X1 series maintains stable cooling output with no frequency derating and no shutdowns. For export air conditioning projects in high-temperature regions such as Middle Eastern deserts and Southeast Asian coasts, T3 certification means the equipment operates reliably even in local extreme climates.
3. Precision Manufacturing · Validated by Tens of Millions of Units
The X1 series adopts high-precision machining processes and precision internal structure design. The rotary rolling piston structure is mature and stable. Through rigorous durability testing and precise engineering validation, it maintains excellent durability and reliability even under long-term, high-frequency operation. The actual installed base of tens of millions of units worldwide proves the X1 series' wide adaptability across various climatic conditions and application scenarios.
4. Compact and Lightweight · Easy Installation and Maintenance
The X1 series has a net weight of 10.7-12.0 kg, which is relatively light among compressors of the same displacement, significantly reducing transportation costs and installation difficulty. The compact design frees up more system layout space for OEMs, while also making replacement during after-sales maintenance more convenient.
5. Multi-Scenario Adaptation · Flexible Applications
The X1 series is not only suitable for residential split air conditioners (wall-mounted and cabinet types), but can also be extended to various refrigeration equipment such as industrial water chillers, commercial display cases (beverage coolers, ice cream machines), heat pump water heaters, and dehumidifiers. One compressor for multiple uses, simplifying model selection and inventory management for customers.
IV. Suitable Applications -
R22 residential split air conditioners (1.5-2.5HP wall-mounted units/cabinet units)
-
R22 light commercial unitary systems and small commercial air conditioners
-
R22 heat pump water heater systems
-
R22 commercial refrigeration equipment (display cases, ice cream machines, dehumidifiers, etc.)
Core Technical Parameters
The X1 series displacement ranges from 10.8 to 18.0 cm³/rev, precisely matching different horsepower requirements as the model number increases:
| Model | Displacement (cm³/rev) | Cooling Capacity (W) | Input Power (W) | COP (W/W) | Net Weight (kg) |
| PH108X1CY-8BGD2 | 10.8 | 1820 | 595 | 3.06 | 10.7 |
| PH120X1CY-8BGD2 | 12.2 | 2090 | 675 | 3.10 | 10.7 |
| PH135X1C-8DZD2 | 13.6 | 2280 | 750 | 3.04 | 12.0 |
| PH150X1C-8DZD2 | 14.8 | 2500 | 820 | 3.05 | 12.0 |
| PH155X1C-8DZD2 | 15.4 | 2600 | 850 | 3.06 | 12.0 |
| PH160X1C-8DZD2 | 16.1 | 2720 | 890 | 3.06 | 12.0 |
| PH165X1C-8DZD2 | 16.5 | 2810 | 920 | 3.05 | 12.0 |
| PH170X1C-8DZD2 | 17.1 | 2920 | 960 | 3.04 | 12.0 |
| PH180X1C-8DZD2 | 17.8 | 3050 | 1025 | 2.98 | 12.0 |
Note: The above data is based on testing under standard conditions with R22 refrigerant.
The entire series achieves a COP of 2.98-3.10 W/W, placing it at the leading level among R22 fixed-speed small-displacement compressors. Standard configuration includes a 25/370μF capacitor, adapted for single-phase 220-240V power supply. Overall unit noise is controlled at 59-60 dB(A), ensuring quiet operation, suitable for installation in residential and light commercial premises.
