Product Overview The Copeland ZP24KSE is a compact semi-hermetic piston compressor utilizing an efficient reciprocating design. Optimized for light commercial refrigeration systems, this compressor features a compact structure, excellent energy efficiency, and reliable operation, making it suitable for space-constrained applications with high energy efficiency requirements. Core Technical Features
High-Efficiency Piston Design
Lightweight aluminum piston with low-friction piston rings
Precision-machined crankshaft system for smooth operation
Optimized suction and discharge valves to reduce flow losses
Compact Motor Design
Class F insulation system, temperature resistance up to 155°C
Forced air cooling design for effective heat dissipation
Wide voltage compatibility (220-240V/50Hz)
Enhanced Reliability Design
High-strength cast iron body for robust structure
Optimized bearing system with long service life
Built-in oil pump lubrication system for reliable lubrication
Technical Specifications
Parameter
Value
Cylinder Displacement (m³/h)
24
Rated Power (kW)
3.0
Refrigeration Capacity (kW)
10.2
Energy Efficiency Ratio (EER)
3.40
Maximum Allowable Speed (rpm)
2900
Application Areas
Commercial refrigerated display cases
Small cold storage rooms
Ice machines
Beverage cooling equipment
Product Advantages
Compatible with eco-friendly refrigerants such as R404A and R448A
Wide operating range (evaporation temperature: -30°C to +10°C)
Multiple built-in protections (overheat protection, phase loss protection, etc.)
Quality Assurance
Design life: 10 years
CE safety certified
Installation Requirements
Ambient temperature: ≤40°C
Storage temperature: -20°C to +60°C
Maximum installation altitude: 2000 meters above sea level
