High Cost Performance Sanyo Scroll Compressor C-SCN903H8H C-SCN903H8T C-SCN903HBK Factory Price Refrigeration Heat Exchange Parts
Share to:
Used for central air conditioning and refrigeration units, with a power of 1.0kW or 10kW, and a structural type of sealed or fully enclosed. Fully enclosed scroll compressor, quantitative displacement, speed of 3000r/min, energy efficiency ratio of 5, suitable for multi split air conditioners such as Midea and Gree
1. Series Highlights Overview The Sanyo C-SCN903 series is a high-performance, fully hermetic scroll compressor. Renowned for its outstanding energy efficiency, extremely low noise and vibration, and exceptional operational reliability, it has become the preferred core component in numerous global high-end commercial Variable Refrigerant Flow (VRF) systems, Rooftop Units (RTUs), and air-source heat pump systems. This series offers various electrical configurations to meet the requirements of different regions and projects.
C-SCN903H8H:Typically denotes a compressor suitable for 50Hz power standards (e.g., 380V 3Ph 50Hz).
C-SCN903H8T:Typically denotes a compressor suitable for 60Hz power standards (e.g., 460V 3Ph 60Hz).
C-SCN903HBK:Likely represents a specific customer-customized version or a variant with different interfaces/protective devices.
Core Value Proposition:To provide system integrators and OEMs with top-tier energy efficiency, unparalleled operational quietness, and long-term stability, thereby enhancing the market competitiveness of the end products. 2. Core Technologies and Competitive Advantages
Advanced Scroll Compression Technology
High Efficiency and Energy Saving:Utilizes an optimized scroll profile design, enabling a continuous and smooth compression process with high volumetric efficiency. This ensures the compressor maintains a high Coefficient of Performance (COP) and Integrated Part Load Value (IPLV) across a wide operating range, significantly reducing system energy consumption.
Smooth and Quiet Operation:Compared to traditional piston compressors, scroll compressors have fewer moving parts and excellent dynamic balance, resulting in extremely low noise and vibration levels, enhancing the comfort of the installation environment.
High Reliability:Simple and compact structure with minimal wear, offering greater resistance to liquid slugging and contaminants, leading to a service life far exceeding that of piston compressors.
Wide Operating Range
Designed for harsh commercial environments, it can operate stably under very high ambient temperatures, ensuring no cooling capacity degradation for air conditioning systems during intense summer heat and strong heating performance for heat pump systems in cold winters.
Built-in Protection Mechanism
The compressor incorporates internal temperature and overload protectors, effectively preventing abnormal conditions such as motor overheating and overcurrent, providing solid protection for the core components and extending service life.
Environmental Refrigerant Compatibility
Fully compatible with eco-friendly HFC refrigerants like R410A, meeting global environmental regulations and future-oriented requirements.
3. Typical Application Areas
Commercial VRF Systems:Serves as the core power source for systems, ideal for office buildings, hotels, shopping malls, etc.
Light Commercial Air Conditioning:Widely used in Rooftop Units (RTUs), air-cooled modular units, and small central air conditioning units.
Air-Source Heat Pumps:Provides an efficient and reliable heat source for winter heating and domestic hot water.
Light Industrial Refrigeration/Air Conditioning:Used in data rooms, communication base stations, and other locations requiring year-round uninterrupted operation.
4. Key Parameters Overview (Typical Values)
Parameter
C-SCN903H8H (50Hz)
C-SCN903H8T (60Hz)
Remarks
Refrigerant
R410A
R410A
Displacement
~ 34.0 cm³/rev
~ 34.0 cm³/rev
Nominal Cooling Capacity
Approx. 11.0 - 12.0 kW
Approx. 12.5 - 13.5 kW
@Standard A/C Conditions (A35℃/E7℃)
Power Supply
3-Phase, 380V, 50Hz
3-Phase, 460V, 60Hz
Lubricant
Ester Oil (POE)
Ester Oil (POE)
Compatible with R410A
Note:The above data represents typical values under standard conditions. Actual performance varies with system design and operating conditions. 5. Why Choose the Sanyo C-SCN903 Series?
Brand Heritage:Incorporates decades of technological accumulation from Sanyo/Panasonic in the compressor field, ensuring guaranteed quality.
High Efficiency and Energy Saving:Directly helps reduce the annual operating costs of systems, complying with green building energy efficiency standards.
Quiet and Comfortable Operation:Particularly suitable for applications with strict noise requirements, such as high-end residences, hospitals, and schools.
Global Recognition:Extensively used in air conditioning products of renowned global brands, proven over time in the market.
