Copeland Refrigeration Compressor Series ZF13KQE ZF15KQE ZF18KQE
Share to:
ZF13KQE Features: Adopting spray technology to control exhaust temperature and optimize low-temperature operating performance. Advantages: The flexible vortex design enhances the ability to withstand liquid impact, and the evaporation temperature can be as low as -40 ° C. ZF15KQE Features: Jet enthalpy increasing technology enhances refrigeration efficiency and is suitable for extreme low-temperature environments. Advantage: Dynamic exhaust valve adjusts pressure, reducing energy consumption under high pressure ratio. ZF18KQE Parameter: R404 refrigerant specific, waveform winding design to reduce noise. Advantages: Compact size, high reliability, suitable for space limited refrigeration systems
Product Overview The Copeland ZF13KQE, ZF15KQE, and ZF18KQE are compact high-efficiency scroll refrigeration compressors utilizing advanced digital scroll technology. Designed for light commercial and medium-duty refrigeration systems, these compressors feature high energy efficiency, smooth operation, and low noise, making them suitable for applications with strict space and energy efficiency requirements. Core Technical Features
Optimized Scroll Design
Asymmetric scroll profile for improved compression efficiency.
Patented flexible design for enhanced liquid tolerance.
Optimized discharge channel to reduce flow losses.
High-Efficiency Motor System
Utilizes high-efficiency permanent magnet synchronous motor (ZF18KQE).
Wide voltage range design (180–264 V/50 Hz).
Built-in temperature and overload protection.
Compact Design
25% smaller footprint compared to traditional compressors.
Lightweight for easy installation and maintenance.
Optimized piping connection design.
Technical Specifications Comparison
Parameter
ZF13KQE
ZF15KQE
ZF18KQE
Displacement (m³/h)
13.2
15.1
18.4
Rated Power (kW)
3.5
4.0
4.8
Refrigeration Capacity (kW)
11.5
13.2
15.8
EER
3.3
3.3
3.3
Noise Level [dB(A)]
62
63
64
Application Areas
Commercial display cases.
Small cold storage rooms.
Convenience store refrigeration units.
Restaurant kitchen refrigeration systems.
Product Advantages
Compatible with eco-friendly refrigerants (R404A/R448A).
Wide operating range (evaporation temperature: -35°C to +10°C).
