The continuous, progressive scroll compression process minimizes clearance volume losses and suction/discharge pressure losses.
Both volumetric efficiency and adiabatic efficiency reach industry-leading levels.
The flexible scroll design adapts to minor pressure fluctuations, further reducing internal leakage.
Digital scroll and variable frequency technology enable stepless capacity modulation from 10% to 100%, delivering outstanding energy efficiency, especially under part-load conditions.
Exceptional Reliability
Utilizes a high-strength cast iron body and precision-machined crankshaft/connecting rod.
Fewer moving parts (only orbiting and fixed scrolls), eliminating vulnerable components like suction and discharge valves.
Low mechanical wear, extremely low failure rate, and significantly longer lifespan than traditional reciprocating compressors.
The internal motor features special insulation materials and vacuum impregnation, offering excellent heat and voltage surge resistance.
II. Operational Performance Advantages
Low Noise and Vibration
Smooth operation as the continuous compression process replaces intermittent impacts.
Significantly reduces noise and vibration levels, enhancing user experience.
Equipped with bottom elastic vibration dampers to effectively minimize vibration transmission.
Strong Starting Capability
Ensures reliable start-up even under conditions with significant pressure differentials.
Crucial for heat pump system restart after defrosting in extreme cold weather.
Good oil and liquid return tolerance improves overall system operational stability.
III. Maintenance and Safety Advantages
Easy Maintenance
Features a detachable design for increased maintenance efficiency.
Quick detachment and installation of attachments reduces maintenance workload.
Equipped with an oil sight glass for convenient monitoring of the lubrication system.
Comprehensive Safety Protection
Includes temperature sensors for real-time system status monitoring.
Automatic power-off protection prevents system overheating.
Built-in motor protection ensures safe operation.
IV. Environmental Protection and Adaptability
Environmentally Friendly and Energy-Saving
Adopts a high-efficiency, energy-saving design to effectively reduce energy consumption.
Compatible with various environmentally friendly refrigerants, including R410A, R32, R134a, R404A/R448A, and CO₂.
Complies with global regulatory trends for phasing out high-GWP refrigerants.
Wide Adaptability
The product line covers a broad range of operating conditions, from low-temperature refrigeration to high-temperature heat pumps.
Capable of adapting to diverse climatic conditions worldwide.
Offers multiple capacity control methods, including fixed-speed, digital scroll, and variable frequency.
Comparison of ZPD34, ZPD42, and ZPD51 Model Features
Model
Cooling Capacity Range
Power
Voltage Configuration
Refrigerant
Application Characteristics
ZPD34
1 kW
1 kW
208-230V 60Hz
R410A
Compact design, suitable for small commercial and premium residential applications.
ZPD42
10.3-14.5 kW
3-5 HP
200-460V 50/60Hz
R22 / R407C
Medium capacity, suitable for medium-sized commercial chiller units.
ZPD51
15.1 kW
15.1 kW
208-230V 60Hz
R410A
Large capacity design, suitable for large commercial air conditioning systems.
ZPD Series Common Features:
All models employ Copeland Scroll® technology.
Feature low noise, high energy efficiency, and high reliability.
Suitable for various applications, including air conditioning, refrigeration, and heat pumps.
With its mature technological platform and outstanding performance, this compressor series has become the preferred choice for a wide range of applications, from residential air conditioning to large-scale industrial refrigeration.
