COPELAND ZP/ZPD SERIES COMPRESSOR R-410A Models ZPD54 ZPD61 ZPD72 ZPD83 Scroll Digital for Refrigeration & Heat Exchange
Share to:
digital scroll ™ Compressors, belonging to the ZPD/ZRD series, are mainly used in air conditioning systems such as split units, rooftop units, unit units, and chiller units. It uses R22, R407C or R410A refrigerants, with infinite adjustment capability, and can output 10% of the nominal cooling capacity, meeting the requirements of precise temperature and humidity control, comfort and energy saving. The compressor is equipped with high and low pressure protection, pressure relief valve, motor overload protection and other devices, making maintenance easy
Product Overview The Copeland ZPD series comprises industrial-grade, high-performance semi-hermetic reciprocating piston refrigeration compressors, specifically engineered for medium-duty commercial refrigeration systems. This series excels in durability, energy efficiency, and maintenance convenience. The ZPD54, ZPD61, ZPD72, and ZPD83 are four closely matched capacity models within this series, offering a complete solution for small to medium-scale refrigeration needs. They are widely used in commercial refrigeration and freezer display applications. Core Features and Advantages
Robust Semi-Hermetic Construction
Utilizes high-strength cast iron crankcases and optimized bearing systems.
Removable cylinder head design facilitates on-site maintenance and part replacement.
Specially designed valve plates ensure smooth and reliable operation.
High-efficiency motor design with built-in protection devices.
Compatible with environmentally friendly refrigerants like R404A and R507.
Wide Operating Range
Evaporation temperature range: -35°C to +10°C.
Suitable for medium and low-temperature applications.
Good liquid tolerance offers greater system adaptability.
Model Specification Comparison
Model
Displacement (cm³/rev)
Refrigeration Capacity (kW) @ -25°C/+40°C (R404A)
Approx. Horsepower (HP)
Primary Application Scenarios
ZPD54
54
3.5 - 4.2
5 - 7 HP
Small cold rooms, commercial refrigerators
ZPD61
61
4.0 - 4.8
7 - 9 HP
Medium display cases, kitchen cold storage
ZPD72
72
4.8 - 5.6
9 - 11 HP
Supermarket freezer cases, small cold stores
ZPD83
83
5.5 - 6.5
11 - 13 HP
Central refrigeration systems, cold chain logistics
Note: Capacity values are approximate and can vary based on operating conditions. Refer to official technical data for precise selection.Typical Application Areas
Freezer and cooler display cases in commercial supermarkets.
Refrigeration equipment in restaurant kitchens.
Food processing and distribution centers.
Small cold storage rooms and cold chain logistics.
Commonly available wear parts reduce maintenance costs.
Modular design allows individual replacement of major components.
Control System Compatibility
Supports various starting methods.
Can be used with electronic expansion valves (EEVs).
Adaptable to intelligent control system requirements.
Selection Guidelines
ZPD54 is suitable for small, independent refrigeration systems.
ZPD61/ZPD72 are ideal for medium-sized commercial establishments.
ZPD83 is designed for applications with larger cooling loads.
Selection should be based on actual cooling capacity requirements and operating conditions.
Important Notes
Must be installed and commissioned by qualified technicians.
Regular inspection of lubricating oil and filters is required.
Implementing a preventive maintenance plan is highly recommended.
This compressor series, known for its reliable performance and cost-effectiveness, is an ideal choice for medium-duty commercial refrigeration applications.
